HZ100

Smart Series Long Reading Integrated RFID Reader

High performance Integrated UHF RFID reader updated from
CL7206B5A, supporting ISO18000-6C protocol, long range RFID reading,
fast identification, excellent multi-tag reading, strong anti-collision,
automatic reading, white list functions.
Widely used fixed asset management, logistic, warehouse inventory,
products tracking transshipment , e parking system vehicle
management, production automation etc.
  • 香水
  • 香水
  • 香水
  • 香水
  • 香水
HZ100 Long reading Integrated RFID Reader
Features
  • Impinj R2000 / E710 / TM600
  • RJ45, RS-232, RS-485, Wiegand
  • working with card reading prompt tone and light strip display
  • Support Online And Remote Upgrade
  • Various software Interfaces
  • IP66 outdoor use
Get Quote
Highlights




Typical applications

* Logistics industry such as, warehouse inventory management, cargo transfer tracking, etc.

* Intelligent vehicle management e.g. vehicle inspection, customs clearance, etc.

*Anti-forgery identification.

*Production automation, parts flow management, etc.

* E-ticketing and identification of personnel cards, etc.

* Power patrol, asset access management, etc.

Features

* Powered by Impinj RAIN RFID E710 chipset, E510 / E310 optional for best cost.

*Kinds of communication interfaces: RJ45, RS232,RS485,Wiegand

*Industrial, installation-friendly I/O connector

* Support RSSI, antenna detection, online update, speed filters





Specifications
  • SDK and firmware
    Firmware Upgrade Demo software / Telnet
    API Support Windows – .NET, C++ and Java SDK
    Android - Java
    Linux platform – C and Java SDK
  • Physical
    Dimensions 276mm×276mm×40mm
    Housing Material Aluminum plate / ABS cover
    Weight Main body 1.4Kgs
    G.W. about 2.6Kgs
    Visual Status Indicators Power/Status LED
  • RFID
    Chipset Impinj RAIN RFID E710/E510/E310 chip
    (Indy R2000 optional)
    Frequency 902-928MHz , 865-868MHz,
    920-925MHz
    Output Power 0dBm-30dBm (±1dBm) adjustable
    9dbi antenna built-in
    Air Protocols ISO/IEC18000-6B,6C / EPC C1Gen2 , C2GEN2
  • Environment
    Operating Temperature -30 - +70°C
    Storage Temperature -40 - +85°C
    Operating Humidity 5-90% non-condensing (+25℃)
    Protection Level IP65
Applications
Intelligent Transportation
Highway RFID Tolling
With the in-depth development of the world economy, the transportation infrastructure has been greatly improved. However, the traffic capacity of the road network is increasingly unable to meet the needs of traffic growth, and traffic congestion is becoming more and more serious, especially at high-speed toll stations. How to realize the effective command, coordinated control and management of various vehicles has become an important issue for traffic safety management department in different countries and regions.
RFID technology (radio frequency identification technology), as a revolutionary solution to security and management, can effectively solve the traffic issues. Hopeland provides a variety of RFID products, including UHF RFID readers, RFID Antennas, RFID vehicle tags, to promote the management of highway toll collections.
View Details
Intelligent Transportation
RFID Parking Access
Currently the vehicle management of parking yard mainly depends on manual recording, through manual transcribing the identification number at the front of the vehicle sequence number (the car in front of the bar code) registration identification.

Registered vehicles cannot be ensured in the field, although for different zoning, established the identity of cardboard. When we want to find out a specific vehicle, the process will be much time-consuming and cumbersome. Sometimes, some cars are not observed, the presence of area stopped for a long time and has not been sold. The stock situation cannot be timely to be controlled. For this situation, we need to implement automatic vehicle access registration, to achieve partition statistics, sales statistics, long stay and early-warning capabilities, making it imperative. Therefore, we need a new system to replace the existing system, which using more scientific and reasonable methods to reach vehicle monitoring.
View Details
Assest Management
Fixed Asset Management
The IT resource management department conducts unified management of the unit's IT equipment assets. At present, the asset management department adopts the traditional manual recording method together with office software and other tools to realize the input and statistics of asset data in the IT asset management of the computer room. The performance is as follows:
1) During the inventory and inspection of IT assets, the management personnel manually confirm the registration cards on the assets one by one, which is a huge workload. Under the current resource situation, it is almost impossible to complete the work of inventorying the assets one by one.
2) The management department defines the asset status information including in the library, entered into the account (after acceptance), reported loss, pending loss, not entered into the account (the contract has been purchased, but not entered into the account), etc. Assets in different states are saved through different databases , which not only easily causes confusion in data management, but also brings a lot of trouble to statistics and query.
3) The data of IT assets are classified and stored by year, which is inconvenient for query and statistics.
4) While doing asset management, it is also engaged in contract management functions. The current data cannot distinguish the asset ledger list one by one.
5) The device status information cannot be obtained in real time.
View Details
Warehousing & Logistics
Smart Warehousing
Modern warehouse storage is not only to complete the simple batch processing of goods in and out, but also to make clear database records of the types, quantities, production attributes, stacking positions and other information of goods in the warehouse. In order to obtain accurate product data and supply chain information at all stages of the logistics chain.

At present, the one-dimensional barcode/two-dimensional barcode identification technology has been widely used in the management of item classification and labeling. However, its barcode technology relies on visible light scanning reflection, has low recognition rate, is easy to break, contaminates, is sensitive to media such as water and oil, and stores a limited amount of information, which affects its application in large-scale logistics management.

RFID radio frequency identification technology is a typical representative of automatic identification technology. It has high recognition accuracy, reliable performance, large amount of stored information, resistance to oil and sewage washing, etc. It is especially suitable for automatic identification requirements in industrial environments. The use of RFID tags to replace barcodes and other identification products can effectively complete the automatic management of warehousing and realize automatic collection, automatic processing and information reporting of product information.
View Details
