HH340

IoT Android RFID Reader

Impinj R2000 chip platform
Open development environment based on Android operating system
Supports MQTT to provide real-time and reliable messaging services
Supports HTTP POST communication
Communication interface types: RJ45, RS485, Wiegand, USB,
Bluetooth, WiFi, 4G
Easy-to-install I/O port connectors
Support antenna port detection, online
  • IoT Android RFID Reader
  • IoT Android RFID Reader
  • IoT Android RFID Reader
  • IoT Android RFID Reader
IoT Android RFID Reader
Features
  • High Sensitivity -85db, Impinj R200 / E710 RAIN RFID
  • PoE Optional
  • Android 9.0
  • Multi-port
  • Multi-type Data Update
  • WiFi/Bluetooth/4G
Get Quote
Highlights

Specifications
  • PHYSICAL CHARACTERISTICS
    Processor MT6765, Octa-Core 2.3Ghz
    Memory Flash 16GB; DRAM2GB
    Operating System: Android 9.0
    Firmware Upgrade Demo software / Web
    API Support Android - Java
    Dimensions 241mm×132mm×36mm
    Weight 1.2Kg
    Housing Material Die-cast aluminum
    Visual Status Indicators Power/Status, Ant 1-4/8
    Operating Temp. -20 - +70°C
    Storage Temp. -40 - +85°C
    Humidity 5-90% non-condensing (+25℃)
    Sealing IP53
  • RFID CHARACTERISTICS
    Air Protocols ISO/IEC18000-6B, 6C / EPC C1Gen2 C2GEN2 optional
    Frequency USA: 902 MHz-928MHz (FCC part 15)
    CN: 920-925MHz (CMIIT)
    Russian / Brazil / Korea / Malaysia / Thailand / other customizable
    Output Power: 0dBm-35dBm (±1dBm) adjustable
    Channel bandwidth: <200KHz
    Anti-collision Support multi-tag / intensive inventory
    Work Mode: Fixed/hop frequency optional
    Communications RJ45, RS-485, OTG, Wiegand
    WiFi : 802.11 a/b/g/n/ac
    4G:LTE-FDD(CAT-7)/LTE-TDD(CAT-7)/ WCDMA/TD-SCDMA/
    EVDO/CDMA/GSM
    Bluetooth:BT v2.1+EDR,3.0+HS,v4.1+HS
    General Purpose I/O 4 inputs(DC 0~24V), 4 outputs(DC_MAX:30V,2A; AC_MAX:125V,0.3A), optically isolated (Terminal Block)
    Power supply DC 24V/2.5A (DC 9V ~ 30V,60W)
    or PoE (IEEE 802.3 af/at/bt), support max 33db output
    Display interface HDMI, support 720P(default)/1080P
    Antenna Ports 4 Reverse Polarity TNC ports; circular or linear polarization; near and far field compatible
Applications
Intelligent Transportation
Highway RFID Tolling
With the in-depth development of the world economy, the transportation infrastructure has been greatly improved. However, the traffic capacity of the road network is increasingly unable to meet the needs of traffic growth, and traffic congestion is becoming more and more serious, especially at high-speed toll stations. How to realize the effective command, coordinated control and management of various vehicles has become an important issue for traffic safety management department in different countries and regions.
RFID technology (radio frequency identification technology), as a revolutionary solution to security and management, can effectively solve the traffic issues. Hopeland provides a variety of RFID products, including UHF RFID readers, RFID Antennas, RFID vehicle tags, to promote the management of highway toll collections.
View Details
Warehousing & Logistics
Smart Warehousing
Modern warehouse storage is not only to complete the simple batch processing of goods in and out, but also to make clear database records of the types, quantities, production attributes, stacking positions and other information of goods in the warehouse. In order to obtain accurate product data and supply chain information at all stages of the logistics chain.

At present, the one-dimensional barcode/two-dimensional barcode identification technology has been widely used in the management of item classification and labeling. However, its barcode technology relies on visible light scanning reflection, has low recognition rate, is easy to break, contaminates, is sensitive to media such as water and oil, and stores a limited amount of information, which affects its application in large-scale logistics management.

RFID radio frequency identification technology is a typical representative of automatic identification technology. It has high recognition accuracy, reliable performance, large amount of stored information, resistance to oil and sewage washing, etc. It is especially suitable for automatic identification requirements in industrial environments. The use of RFID tags to replace barcodes and other identification products can effectively complete the automatic management of warehousing and realize automatic collection, automatic processing and information reporting of product information.
View Details
